Yinlong 66160 LTO 40ah lithium titanate battery for 10kW Energy Storage System

产品详细信息

Product Item:66160 LTO 40ah lithium titanate battery for 10kW Energy Storage System

Product Description

LTO battery is named Lithium titanate battery(Li4Ti5O12), is a new generation lithium ion battery that used the LTO as cathode material instead of graphite, the anode can be LiCoO2, LiMn2O4, LiFePO4,and NiCoMn. as a new type rechargeable lithium battery, LTO battery has great performances of perfect high safety, high stability,super long cycle life and strong temperature tolerance.

Specification

Item	Parameters
Model	OSN-LTO-66160H
Materials	LTO
Nominal capacity	40Ah
Nominal voltage	2.3 V
Dimension	Length: 160±1.5mm
	Diameter: 66±1mm
Weight	1.24±0.1kg
Internal Resistance	≤1mΩ
Operating voltage	Charge cut-off voltage	2.8 V
	Discharge cut-off voltage	1.5 V
Standard charge/discharge current	Charge current	1C(40 A)
	Discharge current	1C(40A)
Maximum charge current	10C
Maximum discharge current	10C
Cycle life	30000 times
Operating Thermal Ambient	Charging	-50℃~ 65℃
	Discharging	-50℃~ 65℃
Storage Thermal Ambient	Short term(within 1 month)	-20℃~ 45℃
	Short term(within 1 year)	-20℃~ 20℃
